Product Specifications
| Cutting Diameter (Inch) | 5/16" |
| Shank Diameter (Inch) | 5/16" |
| Length of Cut (Inch) | 11/16" |
| Overall Length (Inch) | 4" |
| Shank Length (Inch) | 3.312" |
| Cut of Direction | Right Hand |
| Flute Type | Spiral |
| Helix Angle | 45 Degree |
| Coating | TX |
| Number of Flutes | 6 |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
SGS
Number of Flutes:
6
Length of Cut (Inch):
11/16"
Length of Cut (Decimal Inch):
0.6800"
Length of Cut (mm):
17.27mm
Finish/Coating:
TX
Shank Diameter (Inch):
5/16"
Shank Diameter (Decimal Inch):
0.3125"
Shank Diameter (mm):
7.94mm
Overall Length (Inch):
4"
Overall Length (Decimal Inch):
4.0000"
Overall Length (mm):
101.6mm
Helix Angle:
45 Degree
Cutting Direction:
RHC
