SGS 37468 | 0.313" Diameter x 0.313" Shank x 0.938" LOC x 3.000" OAL x 0.090" Radius 5 Flute TM (Ti-NAMITE-M) Coated Corner Radius End Mill

$60.71
Brand:
SGS
Cutting Diameter (Inch):
5/16"
Cutting Diameter (Decimal Inch):
0.3130"
Cutting Diameter (mm):
7.94mm
Shank Diameter (Inch):
5/16"
Shank Diameter (Decimal Inch):
0.3130"
Shank Diameter (mm):
7.94mm
Overall Length (Inch):
3"
Overall Length (Decimal Inch):
3.0000"
Overall Length (mm):
76.20mm
Length of Cut (Inch):
15/16"
Length of Cut (Decimal Inch):
0.9380"
Length of Cut (mm):
23.81mm
Corner Radius (Inch):
1/11"
Corner Radius (Decimal Inch):
0.0900"
Corner Radius (mm):
2.29mm
Finish/Coating:
TM (Ti-NAMITE-M)
Number of Flute:
5
interval quantity:
1
SKU:
25255674
Weight:
1.23 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
SGS 37468 | 0.313" Diameter x 0.313" Shank x 0.938" LOC x 3.000" OAL x 0.090" Radius 5 Flute TM (Ti-NAMITE-M) Coated Corner Radius End Mill

Features:

  • An ideal balance of helix, indexing, flute depth, rake and relief
  • Variable indexing for chatter supression and patented edge geometry for shearing and strength
  • Chatter-free geometry allows deep cutting and high speed machining
  • Enhanced corner geometry with tight tolerance corner radii
  • Excels at roughing, ramping, high speed machining and finishing in a variety of materials

Product Specifications
Manufacturer Part Number37468
Cutting Diameter (Inch)5/16"
Cutting Diameter (Decimal Inch)0.313"
Cutting Diameter (mm)7.94mm
Shank Diameter (Inch)5/16"
Shank Diameter (Decimal Inch)0.313"
Shank Diameter (mm)7.94mm
Length of Cut (Inch)15/16"
Length of Cut (Decimal Inch)0.938"
Length of Cut (mm)23.81mm
Overall Length (Inch)3"
Overall Length (Decimal Inch)3.000"
Overall Length (mm)76.20mm
Corner Radius (Decimal Inch)0.090"
Corner Radius (mm)2.29mm
Shank Diameter Toleranceh6
Flute TypeSpiral
Number of Flutes5
Center CuttingNo
Chip BreakerNo
High PerformanceYes
CoatingTM (Ti-NAMITE-M)
Product TypeCorner Radius End Mill
