SGS 37541 | 0.500" Diameter x 0.500" Shank x 1.500" LOC x 3.500" OAL x 0.060" Radius 5 Flute AlTiN (Ti-NAMITE-A) Coated Chip Breaker Corner Radius End Mill

$158.55
Brand:
SGS
Cutting Diameter (Inch):
1/2"
Cutting Diameter (Decimal Inch):
0.5000"
Cutting Diameter (mm):
12.70mm
Shank Diameter (Inch):
1/2"
Shank Diameter (Decimal Inch):
0.5000"
Shank Diameter (mm):
12.70mm
Overall Length (Inch):
3-1/2"
Overall Length (Decimal Inch):
3.5000"
Overall Length (mm):
88.90mm
Length of Cut (Inch):
1-1/2"
Length of Cut (Decimal Inch):
1.5000"
Length of Cut (mm):
38.10mm
Corner Radius (Inch):
3/50"
Corner Radius (Decimal Inch):
0.0600"
Corner Radius (mm):
1.52mm
Finish/Coating:
AlTiN (Ti-NAMITE-A)
Number of Flute:
5
interval quantity:
1
SKU:
25255746
Weight:
1.23 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
SGS 37541 | 0.500" Diameter x 0.500" Shank x 1.500" LOC x 3.500" OAL x 0.060" Radius 5 Flute AlTiN (Ti-NAMITE-A) Coated Chip Breaker Corner Radius End Mill

Related Products

Features:

  • An ideal balance of helix, indexing, flute depth, rake and relief
  • Variable indexing for chatter supression and patented edge geometry for shearing and strength
  • Chatter-free geometry allows deep cutting and high speed machining
  • Central coolant hole delivers coolant effectively to the cutting zone enhancing chip removal when pocketing or slotting
  • Enhanced corner geometry with tight tolerance corner radii
  • Excels at roughing, ramping, high speed machining and finishing in a variety of materials

Product Specifications
Manufacturer Part Number37541
Cutting Diameter (Inch)1/2"
Cutting Diameter (Decimal Inch)0.500"
Cutting Diameter (mm)12.70mm
Shank Diameter (Inch)1/2"
Shank Diameter (Decimal Inch)0.500"
Shank Diameter (mm)12.70mm
Length of Cut (Inch)1-1/2"
Length of Cut (Decimal Inch)1.500"
Length of Cut (mm)38.10mm
Overall Length (Inch)3-1/2"
Overall Length (Decimal Inch)3.500"
Overall Length (mm)88.90mm
Corner Radius (Decimal Inch)0.060"
Corner Radius (mm)1.52mm
Shank Diameter Toleranceh6
Flute TypeSpiral
Number of Flutes5
Center CuttingNo
Chip BreakerYes
High PerformanceYes
CoatingAlTiN (Ti-NAMITE-A)
Product TypeChip Breaker Corner Radius End Mill
