Features:
- 3 and 4 fute variable pitch geometry for reduced vibration
- Re-engineered fute design for reduced load at high metal removal rates
- Improved design for coolant and MQL
- 4 fute variant for ultimate metal removal rates on high-powered machines
- Ti-NAMITE-B coated for extended tool life
Product Specifications
| Cutting Diameter (mm) | 25.0mm |
| Shank Diameter (mm) | 25.0mm |
| Length of Cut (mm) | 35.0mm |
| Overall Length (mm) | 140mm |
| Cut of Direction | RHC |
| Flute Type | Spiral |
| Reach (mm) | 90mm |
| Corner Radius (mm) | 3 mm |
| Helix Angle | 38 Degree |
| Coating | TiB2 |
| Number of Flutes | 3 |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
SGS
Number of Flutes:
3
Corner Radius (Inch):
1/8"
Corner Radius (Decimal Inch):
0.1181"
Corner Radius (mm):
3mm
Length of Cut (Inch):
1-3/8"
Length of Cut (Decimal Inch):
1.3780"
Length of Cut (mm):
35mm
Finish/Coating:
TB
Shank Diameter (Inch):
63/64"
Shank Diameter (Decimal Inch):
0.9843"
Shank Diameter (mm):
25mm
Overall Length (Inch):
5-33/64"
Overall Length (Decimal Inch):
5.5118"
Overall Length (mm):
140mm
Cutting Direction:
RHC
