Features:
- 3 and 4 fute variable pitch geometry for reduced vibration
- Re-engineered fute design for reduced load at high metal removal rates
- Improved design for coolant and MQL
- 4 fute variant for ultimate metal removal rates on high-powered machines
- Ti-NAMITE-B coated for extended tool life
Product Specifications
| Cutting Diameter (mm) | 12.0mm |
| Shank Diameter (mm) | 12.0mm |
| Length of Cut (mm) | 26.0mm |
| Overall Length (mm) | 83.0mm |
| Cut of Direction | RHC |
| Flute Type | Spiral |
| Reach (mm) | 39mm |
| Corner Radius (mm) | 4.1 mm |
| Helix Angle | 38 Degree |
| Coating | TiB2 |
| Number of Flutes | 3 |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
SGS
Number of Flutes:
3
Corner Radius (Inch):
5/32"
Corner Radius (Decimal Inch):
0.1575"
Corner Radius (mm):
4mm
Length of Cut (Inch):
1-1/32"
Length of Cut (Decimal Inch):
1.0236"
Length of Cut (mm):
26mm
Finish/Coating:
TB
Shank Diameter (Inch):
15/32"
Shank Diameter (Decimal Inch):
0.4724"
Shank Diameter (mm):
12.00mm
Overall Length (Inch):
3-17/64"
Overall Length (Decimal Inch):
3.2677"
Overall Length (mm):
83mm
Cutting Direction:
RHC
