SGS 47843 | 0.630" Diameter x 0.630" Shank x 1.260" LOC x 3.622" OAL x 0.118" Radius 4 Flute TX (Ti-NAMITE-X) Coated Corner Radius End Mill

$183.12
Brand:
SGS
Cutting Diameter (Inch):
46/73"
Cutting Diameter (Decimal Inch):
0.6300"
Cutting Diameter (mm):
16.00mm
Shank Diameter (Inch):
46/73"
Shank Diameter (Decimal Inch):
0.6300"
Shank Diameter (mm):
16.00mm
Overall Length (Inch):
3-51/82"
Overall Length (Decimal Inch):
3.6220"
Overall Length (mm):
92.00mm
Length of Cut (Inch):
1-13/50"
Length of Cut (Decimal Inch):
1.2600"
Length of Cut (mm):
32.00mm
Corner Radius (Inch):
2/17"
Corner Radius (Decimal Inch):
0.1180"
Corner Radius (mm):
3.00mm
Finish/Coating:
TX (Ti-NAMITE-X)
Number of Flute:
4
interval quantity:
1
SKU:
25363124
Weight:
1.23 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
SGS 47843 | 0.630" Diameter x 0.630" Shank x 1.260" LOC x 3.622" OAL x 0.118" Radius 4 Flute TX (Ti-NAMITE-X) Coated Corner Radius End Mill

Features:

  • Open end tooth design to facilitate a smooth and efficient chip evacuation when used in axial applications such as Plunging, Ramping, & Helical Interpolation
  • Variable rake geometry alters and controls the cutting dynamic taking chatter suppression to an unprecedented level
  • Unequal helix design and Unequal flute spacing helps to disrupt the rhythmic pattern created by the cutting edge helping to suppress damaging harmonics
  • End teeth featuring a wiper flat to increase corner strength and significantly improve workpiece floor surface finish
  • Optimized tool life and high metal removal rates through Kyocera proprietary PVD Ti-NAMITE-X (TX) coating
  • Enhanced corner geometry with tight tolerance corner radii

Product Specifications
Manufacturer Part Number47843
Cutting Diameter (Decimal Inch)0.630"
Cutting Diameter (mm)16.00mm
Shank Diameter (Decimal Inch)0.630"
Shank Diameter (mm)16.00mm
Length of Cut (Decimal Inch)1.260"
Length of Cut (mm)32.00mm
Overall Length (Decimal Inch)3.622"
Overall Length (mm)92.00mm
Corner Radius (Decimal Inch)0.118"
Corner Radius (mm)3.00mm
Shank Length (Decimal Inch)2.360"
Shank Length (mm)59.94mm
Shank Diameter Toleranceh6
Flute TypeSpiral
Number of Flutes4
Center CuttingYes
Chip BreakerNo
High PerformanceYes
CoatingTX (Ti-NAMITE-X)
Product TypeCorner Radius End Mill
