Features:
- High-performance point design stabilizes on entry for exceptional hole size and cylindricity while also allowing for low thrust force and extended tool life
- Internal coolant hole improves coolant flow to extend tool life and aid in chip evacuation
- 4-margin design improves hole straightness and roundness while providing improved stability for difficult applications like cross holes and when exiting on angle
- Proprietary Ti-NAMITE-X coating and industry leading carbide substrate provides exceptional wear resistance and toughness for demanding applications
- Recommended for materials ≤ 50HRc (475 Bhn)
Product Specifications
| Manufacturer Part Number | 66803 |
| Size | 13.50mm |
| Cutting Diameter (Decimal Inch) | 0.532" |
| Cutting Diameter (mm) | 13.50mm |
| Shank Diameter (Decimal Inch) | 0.551" |
| Shank Diameter (mm) | 14.00mm |
| Flute Length (Decimal Inch) | 7.441" |
| Flute Length (mm) | 189.00mm |
| Usable Length (Decimal Inch) | 6.644" |
| Usable Length (mm) | 168.75mm |
| Overall Length (Decimal Inch) | 9.213" |
| Overall Length (mm) | 234.00mm |
| Shank Length (Decimal Inch) | 1.772" |
| Shank Length (mm) | 45.00mm |
| Shank Diameter Tolerance | h6 |
| Point Angle (Degree) | 137 Degree |
| Flute Type | Spiral |
| Number of Margins | 4 |
| Number of Flutes | 2 |
| Reach (xD) | 12xD |
| Center Cutting | No |
| Double Margins | Yes |
| High Performance | Yes |
| Self Centering | Yes |
| Coating | TX (Ti-NAMITE-X) |
| Product Type | Extra Long Drill Bit |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
SGS
Overall Length (Inch):
9-13/61"
Overall Length (Decimal Inch):
9.2130"
Overall Length (mm):
234.00mm
Finish/Coating:
TX (Ti-NAMITE-X)
Drill Point Angle:
137 Degree
