Features
- Provides quick, accurate measurement of O.D., I.D. and depth
- 1/64" graduations on the yellow outer scale, and .01" on the white inner scale
- Shows measurements as fractions
- Lock screws for sliding jaw and dial bezel
- Adjustable bezel
- Thumb-operated fine adjustment roll
- Covered rack depth rod
- Hardened stainless steel bar, measuring surfaces, rack, gears and depth rod
- Knife-edge contacts
- Positive, spring-loaded double pinion anti-backlash control
- Positive, spring-loaded double pinion anti-backlash control
- 1/64" graduations on the yellow outer scale, and .01" on the white inner scale
Product Specifications
| Range (in) | 0-6" |
| Graduations (in) | 0.0100" |
| Revolution Range (in) | 1" |
| Bar Graduations | .100" |
| Construction Material | Stainless Steel |
| Dial Color | White |
| Inside Jaw Depth (in) | 5/8" |
| Inside Jaw Depth (mm) | 16mm |
| Outside Jaw Depth (in) | 1-1/2" |
| Outside Jaw Depth (mm) | 38mm |
| Case Type | Plastic |
| Accuracy (in) | +/-.002" |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Starrett
Maximum Measurement (Inch):
6"
Dial Graduation (Inch):
0.0100"
Accuracy (Decimal Inch):
+/-.002"
Jaw Length (Inch):
1-1/2"
Range Per Revolution (Inch):
1"
Range Per Revolution (Decimal Inch):
1"
Dial Color:
White
Material:
Stainless Steel
Ships:
From Manufacturer
interval quantity:
1
