Features
- Half as many bar graduations as conventional single-vernier tools
- Easy to read
- Machine divided graduations
- Tight, smoothly fitted slides
- No glare Starrett satin chrome finish
- Long 50-division vernier scales
- Open-face design
- Screw-type adjusting nut allows for fine measuring adjustments and lock nut holds measurements
- Fine tool steel construction
- Hardened, ground and lapped measuring surfaces
Product Specifications
| Range (in) | 0-24" |
| Range (mm) | 600mm |
| Graduations (in) | 0.0010" |
| Graduations (mm) | 0.02mm |
| Accuracy (in) | +/-.0005" per foot |
| Accuracy (mm) | +/-.01mm per 300mm |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Starrett
Minimum Measurement (Inch):
0
Maximum Measurement (Inch):
24"
Graduation (mm):
0.02mm
Ships:
From Manufacturer
