Features
- Built for gaging dimensions in tight places
- Equipped with high precision, low friction movements and frictionally adjustable bezels for quick, positive zero setting
- No-glare, white eggshell finish dials
- Black bezel, silver finish on case
- Furnished with balanced dial, jeweled bearings and lug-on center back
- Black bezel, silver finish on case
- Unbreakable crystal
- Hardened stainless steel bottom stems can be held in fixtures without cramping rack action
- Hardened stainless steel stem
- Hardened stainless steel rack and spindle
- Hardened stainless steel gears and pinions
- The case is light but sturdy, with a hardened, precision stainless steel rack that rides in bronze bushings
- No-glare satin finish on case
- Direct acting compression spring eliminates side friction
- Contact points and backs can be ordered individually. Order by part number/EDP number
- Frictionally adjustable bezels for quick, positive zero setting
- Easy readability with the best, balanced style of graduation and number combination
- Balanced and tapered hands are easy to follow
- Furnished with balanced dial, jeweled bearings and lug-on-center back.
Product Specifications
| Graduations (in) | .001" |
| Total Range (in) | .100" |
| Range One Rev. (in) | .040" |
| Dial Reading | 0-20-0 |
| Dial Color | White |
| Stem Diameter (in) | .2185" |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Starrett
Type:
Miniature Dial Indicator
Maximum Measurement (Inch):
3/32"
Maximum Measurement (Decimal Inch):
0.1000"
Maximum Measurement (mm):
2.54mm
Dial Graduation (Inch):
0"
Dial Graduation (Decimal Inch):
0.0010"
Dial Graduation (mm):
0.025mm
Dial Reading:
0-20-0
Dial Diameter (Inch):
1-1/4"
Dial Diameter (Decimal Inch):
1.2500"
Dial Diameter (mm):
32mm
Dial Color:
White
Ships:
From Manufacturer
