Features
- Starrett satin chrome finish - no glare - resists rust on all reading surfaces
- Advanced sleeve design with staggered lines and distinct figures for precise and easy readability
- Quick-reading figures
- Extremely hard and stable one-piece spindle (the heart of our accuracy and long life)
- Micro-lapped measuring face for flatness and squareness
- Quick and easy adjustment
Product Specifications
| Micrometer Type | Mechanical Micrometer Head |
| Range (mm) | 0-25mm |
| Graduations (mm) | 0.001mm |
| Spindle Material | Carbide |
| Lock Nut Type | Ring Type Knurled |
| Spindle Type | Flat |
| Thimble Type | Ratchet |
| Accuracy (mm) | +/-.00075mm |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Starrett
Minimum Measurement (mm):
0mm
Maximum Measurement (mm):
25mm
Spindle Diameter (Inch):
1/2"
Spindle Diameter (Decimal Inch):
0.5000"
Spindle Diameter (mm):
12.70mm
Overall Length (Inch):
5"
Overall Length (Decimal Inch):
5.0000"
Overall Length (mm):
127mm
Graduation (mm):
0.001mm
Spindle Type:
Flat
Material:
Carbide
Finish/Coating:
Satin Chrome
Ships:
From Manufacturer
