Features
- Ruggedly constructed for milling, drilling, shaping, grinding and many other machine shop applications
- Body is made of high quality ductile cast iron, resists deflection or bending
Product Specifications
| Manufacturer Part Number | 329235 |
| Jaw Width (mm) | 200mm |
| Orientation Type | Horizontal |
| Number of Stations | 1 |
| Base Motion Type | Stationary |
| Jaw Opening Capacity (mm) | 300mm |
| Operation Type | Manual |
| Jaw Height (mm) | 65mm |
| Model Number | HP-80G |
| Base Length (mm) | 710mm |
| Overall Length (mm) | 800mm |
| Maximum Clamping Force (kgf.m) | 8500 |
| Overall Width (mm) | 280mm |
| Overall Height (mm) | 158mm |
| Product Type | Hydraulic Machine Vise |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
STM
Width (Inch):
7-7/8"
Width (Decimal Inch):
7.8740"
Width (mm):
200.00mm
