| EDP Number | 14U4ARP |
| Product Code-ANSI | AOET11T332PEFR-S-H20 |
| Manufacturer Grade Identification | H20 |
| Series | WEZ |
| Maximum Depth of Cut (mm) | 9.50mm |
| Cutting Edge Length (Decimal Length) | 0.4803" |
| Cutting Edge Length (mm) | 12.20mm |
| Nose Radius (Decimal Inch) | 0.1260" |
| Nose Radius (mm) | 3.20mm |
| Insert Thickness (Decimal Inch) | 0.1339" |
| Insert Thickness (mm) | 3.40mm |
| Insert Style | AOET |
| Insert Side | Single |
| Insert Size | 11T3 |
| Chip Breaker | S |
| Tolerance Class | E |
| Insert Hand | R |
| Insert Material | Carbide |
