| EDP Number | 16V9FJQ |
| Product Code-ANSI | 2NUCNGA431HS-BN7115 |
| Product Code-ISO | 2NU-CNGA120404HS |
| Manufacturer Grade Identification | BN7115 |
| Series | BN7115 |
| Effective Length (Inch) | 0.0945" |
| Effective Length (mm) | 2.40mm |
| Nose Radius (Inch) | 0.0157" |
| Nose Radius (mm) | 0.40mm |
| Inscribed Circle Diameter (Inch) | 0.5000" |
| Inscribed Circle Diameter (mm) | 12.70mm |
| Hole Diameter (mm) | 5.16mm |
| Insert Thickness (Inch) | 0.1874" |
| Insert Thickness (mm) | 4.76mm |
| Insert Size | 431 |
| Corner Angle | 80 Degree |
| Relief Angle | 0 Degree |
| Rake Angle | Negative |
| Insert Material | CBN |
| Insert Style | CNGA |
| Tolerance Class | G |
| Coating | Uncoated CBN |
| Insert Holding Method | Pin & Clamp |
| Standard Designation of the Grade, Main Application | Powdered Metal |
