| EDP Number | 16V9WJJ |
| Product Code-ANSI | 2NUVNGA332LF-BN7115 |
| Product Code-ISO | 2NU-VNGA160408LF |
| Manufacturer Grade Identification | BN7115 |
| Series | BN7115 |
| Effective Length (Inch) | 0.0748" |
| Effective Length (mm) | 1.90mm |
| Nose Radius (Inch) | 0.0315" |
| Nose Radius (mm) | 0.80mm |
| Inscribed Circle Diameter (Inch) | 0.3750" |
| Inscribed Circle Diameter (mm) | 9.525mm |
| Hole Diameter (mm) | 3.81mm |
| Insert Thickness (Inch) | 0.1874" |
| Insert Thickness (mm) | 4.76mm |
| Insert Size | 332 |
| Corner Angle | 35 Degree |
| Relief Angle | 0 Degree |
| Rake Angle | Negative |
| Insert Material | CBN |
| Insert Style | VNGA |
| Tolerance Class | G |
| Coating | Uncoated CBN |
| Insert Holding Method | Pin & Clamp |
| Standard Designation of the Grade, Main Application | Powdered Metal |
