Product Specifications
EDP Number | 19P7CHV |
Product Code-ANSI | CNMG643EEG-AC8025P |
Product Code-ISO | CNMG190612N-EG |
Manufacturer Grade Identification | AC8025P |
Series | AC8000P |
Cutting Edge Length (Decimal Inch) | 0.7598" |
Cutting Edge Length (mm) | 19.30mm |
Nose Radius (Decimal Inch) | 0.0472" |
Nose Radius (mm) | 1.20mm |
Inscribed Circle Diameter (Decimal Inch) | 0.7500" |
Inscribed Circle Diameter (mm) | 19.05mm |
Hole Diameter (mm) | 7.94mm |
Insert Thickness (Decimal Inch) | 0.2500" |
Insert Thickness (mm) | 6.35mm |
Relief Angle | 0 Degree |
Rake Angle | Negative |
Insert Material | Carbide |
Tolerance Class | M |
Chip Breaker | EEG |
Corner Angle | 80 |
Insert Style | CNMG |
Primary Workpiece Material | Steel |
Coating | Absotech |
Coating Process | CVD |
Standard Designation of the Grade, Main Application | P25, P30, P20 |
Insert Holding Method | Pin & Clamp |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Sumitomo
Insert Style:
CNMG
Insert Size:
643
Material:
Carbide
Length (Inch):
3/4"
Length (Decimal Inch):
0.7598"
Length (mm):
19.30mm
Inscribed Circle (Inch):
3/4"
Inscribed Circle (Decimal Inch):
0.7500"
Inscribed Circle (mm):
19.05mm
Thickness (Inch):
1/4"
Thickness (Decimal Inch):
0.2500"
Thickness (mm):
6.35mm
Corner Radius (Inch):
1/16"
Corner Radius (Decimal Inch):
0.0472"
Corner Radius (mm):
1.20mm
Manufacturer's Grade:
AC8025P
interval quantity:
10
