| EDP Number | 2600W7X |
| Product Code-ANSI | GNDML126K-070J |
| Series | GND |
| Insert Width (Inch) | 0.2500" |
| Insert Width (mm) | 6.35mm |
| Head Length (Inch) | 1.7720" |
| Maximum Depth of Cut (Inch) | 0.7000" |
| Maximum Depth of Cut (mm) | 17.78mm |
| Shank Width (Inch) | 0.7500" |
| Shank Height (Inch) | 0.7500" |
| Overall Length (Inch) | 5.0000" |
| Insert Holding Method | Clamp |
| Coolant Through | Yes |
| Hand | Left Hand |
| Tool Holder Style | Multi-Function OD Grooving Tool, Internal Coolant |
