Techniks 04010-5/32 | 0.141" - 0.156" Capacity x 5/32" Shank x 1.379" Width TG100 Steel Super Precision Collet

About This Item

Techniks mission is to provide high-quality and innovative solutions that optimize manufacturing processes for customers engaged in metalworking, composites machining, and woodworking to meet the most challenging applications, improve machining processes, and create cost efficiencies.

Techniks Precision TG Spring Collets are Swiss ground and hand inspected to ensure that T.I.R. is 0.0004" or less. They have a clamping range of 1/64".

Product Specifications

UNSPSC Code	27112808
Series	TG100
Capacity (in)	0.1563 - 0.1407
Capacity (mm)	3.969 - 3.572
Type	Precision Spring Collet
Style	Single Angle
Unit of Tool	Inch
Number of Pieces	N/A
Incremental Division	N/A
Shank Size (in)	0.1563
Shank Size (mm)	3.969
Overall Length (in)	2.375
Overall Length (mm)	60.33
Square Size (in)	N/A
Square Size (mm)	N/A
Tap Range (in)	N/A
Tap Range (mm)	N/A
Tap Size (in)	N/A
Tap Size (mm)	N/A
