Features:
- H5 bore tolerance for improved concentricity and tool life
- Taper ground to AT3 specification for maximum spindle contact
- Balanced to 15,000 RPM at G6.3
Product Specifications
| Taper | SBT40 |
| Body Diameter (mm) | 44.45mm |
| Body Width (mm) | 44.45mm |
| Overall Diameter (mm) | 63mm |
| Bore Size (mm) | 12mm |
| Projection (mm) | 45mm |
| Nose Diameter (mm) | 38.1mm |
| Overall Length (mm) | 110.4mm |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Techniks
Taper Size:
BT40
Nose Diameter (mm):
38.10mm
Overall Length (mm):
110.40mm
Overall Diameter (mm):
63.00mm
Bore Size (mm):
12.00mm
interval quantity:
1
