Techniks 28.653.61.300 | 1.75" Diameter x 0.625" Size x 6.575" OAL End Mill Holder

$298.00 $208.60
(You save $89.40)
Brand:
Techniks
Taper Size:
BT40
Body Diameter (Decimal Inch):
1.7500"
Nose Diameter (Decimal Inch):
1.5000"
Overall Length (Decimal Inch):
6.5750"
Overall Diameter (Decimal Inch):
2.4800"
Bore Size (Decimal Inch):
0.6250"
interval quantity:
1
SKU:
55030994
UPC:
Weight:
3.20 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout

Features:

  • H5 bore tolerance for improved concentricity and tool life
  • Taper ground to AT3 specification for maximum spindle contact
  • Balanced to 15,000 RPM at G6.3

Product Specifications
TaperSBT40
Body Diameter (Inch)1.75"
Body Width (Inch)1.75"
Overall Diameter (Inch)2.48"
Bore Size (Inch)0.625"
Projection (Inch)3"
Nose Diameter (Inch)1.5"
Overall Length (Inch)6.575"
Material8620 Steel
