Techniks 49003 | DAT40-A Pull Stud

$27.00 $18.90
(You save $8.10)
Ships:
From Partner Facility
Brand:
Techniks
Type:
Standard
Taper Size:
DAT40
Thread Size:
M16
Angle Radius (Degree):
15 Degrees
Knob Diameter (mm):
19mm
Style:
DIN 69871 A
Through Coolant:
No
Ships:
From Partner Facility
SKU:
40002915
UPC:
650229419529
Weight:
0.20 LBS
Shipping:
Calculated at Checkout

Techniks_brand_logo

Techniks mission is to provide high-quality and innovative solutions that optimize manufacturing processes for customers engaged in metalworking, composites machining, and woodworking to meet the most challenging applications, improve machining processes, and create cost efficiencies.

All mating surfaces are precision ground. Manufactured to the highest standards for maximum safety and long life. Hardened for maximum longevity.

Product Specifications
UNSPSC Code 20111707
For Use With DAT40 Taper Holders
Style DIN 69871 A
Threads M16
Knob Diameter 19mm
Angle 15 Degree
Neck 14mm
Hole 7mm
Overall Length 54mm
Flat Size N/A
Spindle Taper DAT40 Taper Holders
Diameter 23mm
Size N/A
