Features:
- Rolled threads maintain material grain structure improving thread strength up to 20%
- Each MegaFORCE Retention knob is magnetic particle tested to ensure material integrity and physical soundness
- Tested at 2.5X the pulling forces of the drawbar
Product Specifications
| Taper Size | CAT50 |
| Degree | 45° |
| Head Diameter (Inch) | 0.906" |
| Neck Diameter (Inch) | 0.669" |
| Flange to Top Length (Inch) | 1.78" |
| Flange to Center of head Length (Inch) | 1.386" |
| Thread | 1-8 |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Techniks
Taper Size:
CAT50
Overall Length (Decimal Inch):
3.3540"
Material:
Steel
Neck Diameter (Decimal Inch):
0.6690"
Pilot Diameter (Decimal Inch):
0.6690"
interval quantity:
1
