Techniks 8177788 | A12Q-SDUCL-3 (3/4"-S-BB-CT-LH) Indexable Boring Bar

About This Item

Techniks mission is to provide high-quality and innovative solutions that optimize manufacturing processes for customers engaged in metalworking, composites machining, and woodworking to meet the most challenging applications, improve machining processes, and create cost efficiencies.

Product Specifications

DESIGNATION	A12Q-SDUCL-3 (3/4"-S-BB-CT-LH)
UNSPSC Code	23242106
GRADE	N/A
CHIP BREAKER	N/A
IC	N/A
THICKNESS	N/A
RADIUS	N/A
CHAMFER WIDTH	N/A
HEIGHT	0.75
LENGTH	7
HOLDER ANGLE	93
MIN. BORE DIA.	0.984
CUTTING DIAMETER	N/A
ARBOR or SHANK DIAMETER	N/A
SHANK LENGTH	N/A
ASPECT RATIO	N/A
MATERIAL	Steel
COATING	N/A
HOLDING SYSTEM	Screw
GAUGE INSERT	DCMT 32.52
GAUGE INSERT (external)	N/A
GAUGE INSERT (internal)	N/A
CHIP BREAKER FUNCTION	N/A
IPR (min)	N/A
IPR (max)	N/A
DOC (min)	N/A
DOC (max)	N/A
IPT (min)	N/A
IPT (max)	N/A
CUTTER or SHANK	N/A
SHANK STYLE	N/A
MAX Ap (DOC)	N/A
CUTTER APPROACH ANGLE	N/A
COOLANT THRU	Yes
NUMBER OF TEETH	N/A
INTERNAL or EXTERNAL	N/A
WEIGHT PER PIECE	0.8
QTY PER BOX	N/A
CLAMP	N/A
CLAMP SCREW	N/A
SHIM
SHIM SCREW	N/A
WRENCH	9355555
SHIM PIN
SCREW	6811259
LEVER
