Techniks 84063-19/32 | 19/64" Capacity x 1.379" Width x 19/64" Shank TG100 Steel Coolant Collet

About This Item

Techniks mission is to provide high-quality and innovative solutions that optimize manufacturing processes for customers engaged in metalworking, composites machining, and woodworking to meet the most challenging applications, improve machining processes, and create cost efficiencies.

Techniks Swiss Ground Coolant Collets are the most accurate in the industry with T.I.R. of 0.0004" or less. The Rubber Sealed Plugs are perfect for coolant applications up to 750 PSI of Coolant Pressure. They offer a clamping range of up to 1/64" for added versatility.

Product Specifications

UNSPSC Code	27112808
Series	TG100
Capacity (in)	0.594 - 0.578
Capacity (mm)	15.081 - 14.684
Type	Plugged Coolant Collet
Style	Single Angle
Unit of Tool	Inch
Number of Pieces	N/A
Incremental Division	N/A
Shank Size (in)	0.594
Shank Size (mm)	15.081
Overall Length (in)	2.375
Overall Length (mm)	60.33
Square Size (in)	N/A
Square Size (mm)	N/A
Tap Range (in)	N/A
Tap Range (mm)	N/A
Tap Size (in)	N/A
Tap Size (mm)	N/A
