Techniks 8655545 | STGCL-12-3C (3/4"-TT-LH) Indexable Turning Toolholder

$89.00 $88.11
(You save $0.89)
Ships:
From Partner Facility
Brand:
Techniks
Lead Angle:
91
Shank Height (Decimal Inch):
0.7500"
Overall Length (Decimal Inch):
5"
Ships:
From Partner Facility
IsDiscontinued:
SKU:
23000773
UPC:
Weight:
0.95 LBS
Shipping:
Calculated at Checkout
Techniks 8655545 | STGCL-12-3C (3/4"-TT-LH) Indexable Turning Toolholder

Product Specifications
DESIGNATION STGCL-12-3C (3/4"-TT-LH)
UNSPSC Code 23242106
GRADE N/A
CHIP BREAKER N/A
IC N/A
THICKNESS N/A
RADIUS N/A
CHAMFER WIDTH N/A
HEIGHT 0.75
LENGTH 5
HOLDER ANGLE 91
MIN. BORE DIA. N/A
CUTTING DIAMETER N/A
ARBOR or SHANK DIAMETER N/A
SHANK LENGTH N/A
ASPECT RATIO N/A
MATERIAL Steel
COATING N/A
HOLDING SYSTEM Screw
GAUGE INSERT TCMT 32.52
GAUGE INSERT (external) N/A
GAUGE INSERT (internal) N/A
CHIP BREAKER FUNCTION N/A
IPR (min) N/A
IPR (max) N/A
DOC (min) N/A
DOC (max) N/A
IPT (min) N/A
IPT (max) N/A
CUTTER or SHANK N/A
SHANK STYLE N/A
MAX Ap (DOC) N/A
CUTTER APPROACH ANGLE N/A
COOLANT THRU N/A
NUMBER OF TEETH N/A
INTERNAL or EXTERNAL N/A
WEIGHT PER PIECE 0.95
QTY PER BOX N/A
CLAMP
CLAMP SCREW
SHIM 9333555
SHIM SCREW 9319547
WRENCH 9355555
SHIM PIN
SCREW 9318446
LEVER N/A
