Features:
- H5 bore tolerance for improved concentricity and tool life
- Balance to 15,000 RPM @ G6.3
- Coolant tubes for through-spindle coolant
Product Specifications
| Taper | HSK63A |
| Body Diameter (inch) | 1.89" |
| Body Width (inch) | 1.89" |
| Overall Diameter (Inch) | 2.48" |
| Bore Size (Inch) | 0.75" |
| Projection (Inch) | 3.75" |
| Nose Diameter (Inch) | 1.75" |
| Overall Length (inch) | 5.01" |
| Material | 8620 Steel |
