Product Specifications
| Manufacturer Part Number | CD81510 |
| Drill Diameter (Inch) | 7/32" |
| Drill Diameter (Decimal Inch) | 0.219" |
| Shank Diameter (Inch) | 7/32" |
| Shank Diameter (Decimal Inch) | 0.219" |
| Overall Length (Inch) | 3-3/4" |
| Overall Length (Decimal Inch) | 3.750" |
| Flute Length (Inch) | 2-1/2" |
| Flute Length (Decimal Inch) | 2.500" |
| Number of Flute | 2 |
| Point Angle (Degree) | 135 Degree |
| Substrate | Cobalt |
| Coating | Gold Oxide |
| Product Type | Jobber Length Drill Bit |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Titan USA
Drill Diameter (Inch):
7/32"
Drill Diameter (Decimal Inch):
0.2190"
Drill Diameter (mm):
5.56mm
Shank Diameter (Inch):
7/32"
Shank Diameter (Decimal Inch):
0.2190"
Shank Diameter (mm):
5.56mm
Overall Length (Inch):
3-3/4"
Overall Length (Decimal Inch):
3.7500"
Overall Length (mm):
95.25mm
Drill Point Angle:
135 Degree
Number of Flutes:
2
Material:
Cobalt
Finish/Coating:
Gold Oxide
interval quantity:
1
