Features:
- Offered in stub, regular, long, and extra long length styles
- 4 flutes
- TiN coating provides improved performance in a wide variety of materials, and generally used in applications with lower cutting speeds
- TiCN coating adds enhanced performance when AlTiN cannot be used
- AlTiN coating offers increased wear and heat resistance
- Solid Carbide
- CNC ground in the USA
Product Specifications
| Manufacturer Part Number | TC10580 |
| Cutter Diameter (Inch) | 1.2500" (1-1/4) |
| Length of Cut (Inch) | 2.0000" (2) |
| Shank Diameter (Inch) | 1.2500" (1-1/4) |
| Overall Length (Inch) | 4.5000" (4-1/2) |
| Number of Flutes | 4 |
| Substrate | Carbide |
| Coating | Uncoated |
| Product Type | Square End Mill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Titan USA
Mill Diameter (Inch):
1-1/4"
Mill Diameter (Decimal Inch):
1.2500"
Mill Diameter (mm):
31.75mm
Number of Flutes:
4
Length of Cut (Inch):
2"
Length of Cut (Decimal Inch):
2.0000"
Length of Cut (mm):
50.80mm
Material:
Carbide
Finish/Coating:
Uncoated
Shank Diameter (Inch):
1-1/4"
Shank Diameter (Decimal Inch):
1.2500"
Shank Diameter (mm):
31.75mm
Overall Length (Inch):
4-1/2"
Overall Length (Decimal Inch):
4.5000"
Overall Length (mm):
114.30mm
interval quantity:
1
