Features:
- VI-Pro variable index geometry offers outstanding performance in a wide range of materials, including high temp alloys, stainless steels, alloy steels, cast iron, and titanium
- Engineered with chipbreaker geometry for optimal chip evacuation, reduced harmonics, and reduced tool pressure
- 4 flutes
- Large core and eccentric relief for improved tool life
- Post-polished AlCrO-MAX coating increases wear and high heat resistance
- Solid carbide
- CNC ground in the USA
Product Specifications
| Manufacturer Part Number | TC28094 |
| Cutting Diameter (Inch) | 0.7500" (3/4) |
| Shank Diameter | 0.7500" (3/4) |
| Overall Length (Inch) | 7.0000" (7) |
| Length of Cut (Inch) | 4.0000" (4) |
| Number of Flutes | 4 |
| Coating | ALCRO-MAX |
| Substrate | Carbide |
| Product Type | Square End Mill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Titan USA
Overall Length (Inch):
7"
interval quantity:
1
