Features:
- Excellent performance in hardened steels, titanium, Inconel, and high temp alloys
- Engineered with chipbreaker geometry for optimal chip evacuation, reduced harmonics, and reduced tool pressure
- Corner radius for increased edge strength
- Higher helix for enhanced cutting action
- 4 flutes
- AlTiN coating offers increased wear and heat resistance
- Solid carbide
- CNC ground in the USA
Product Specifications
| Manufacturer Part Number | TC29785 |
| Cutting Diameter (Inch) | 0.1250" (1/8) |
| Shank Diameter | 0.1250" (1/8) |
| Overall Length (Inch) | 3.0000" (3) |
| Length of Cut (Inch) | 1.0000" (1) |
| Corner Radius (Inch) | 0.0100" |
| Number of Flutes | 4 |
| Coating | Uncoated |
| Substrate | Carbide |
| Product Type | Roughing End Mill |
