This 4 flute, square profile offering of Titan USA Micro End Mills are CNC ground in the USA from solid carbide and are AlTiN coated for increased wear and heat resistance.
Features:
- 4 flutes
- Center cutting
- Solid carbide
- CNC ground in the USA
Product Specifications
| Manufacturer Part Number | TC58024 |
| Cutting Diameter (Inch) | 0.0240" |
| Cutting Diameter (mm) | 0.6 mm |
| Shank Diameter (Inch) | 0.1250" (1/8) |
| Overall Length (Inch) | 1.5000" (1-1/2) |
| Length of Cut (Inch) | 0.0720" |
| Number of Flutes | 4 |
| Coating | Uncoated |
| Substrate | Carbide |
| Product Type | Square End Mill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Titan USA
Cutter Diameter (Inch):
2/83"
Cutter Diameter (Decimal Inch):
0.0240"
Cutter Diameter (mm):
0.60mm
Shank Diameter (Inch):
1/8"
Shank Diameter (Decimal Inch):
0.1250"
Shank Diameter (mm):
3.18mm
Length of Cut (Inch):
1/14"
Length of Cut (Decimal Inch):
0.0720"
Length of Cut (mm):
1.83mm
Overall Length (Inch):
1-1/2"
Overall Length (Decimal Inch):
1.5000"
Overall Length (mm):
38.10mm
Helix Angle:
30 Degree
Number of Flutes:
4
Finish/Coating:
Uncoated
Material:
carbide
interval quantity:
1
