Titan USA TE81249 | 0.8750" (7/8) Diameter x 0.7500" (3/4) Shank x 4.1250" (4-1/8) OAL x 1.8750" (1-7/8) LOC 4 Flute Uncoated Cobalt Square End Mill

$62.37
Brand:
Titan USA
Mill Diameter (Inch):
7/8"
Mill Diameter (Decimal Inch):
0.8750"
Mill Diameter (mm):
22.23mm
Number of Flutes:
4
Length of Cut (Inch):
1-7/8"
Length of Cut (Decimal Inch):
1.8750"
Length of Cut (mm):
47.63mm
Material:
Cobalt
Finish/Coating:
Uncoated
Shank Diameter (Inch):
3/4"
Shank Diameter (Decimal Inch):
0.7500"
Shank Diameter (mm):
19.05mm
Overall Length (Inch):
4-1/8"
interval quantity:
1
SKU:
25231598
Weight:
0.52 LBS
Shipping:
Calculated at Checkout

Features:

  • Center cutting
  • Weldon flat
  • M42 cobalt
  • CNC ground in the USA

Product Specifications
Manufacturer Part NumberTE81249
Cutting Diameter (Inch)0.8750" (7/8)
Shank Diameter 0.7500" (3/4)
Overall Length (Inch)4.1250" (4-1/8)
Length of Cut (Inch)1.8750" (1-7/8)
Number of Flutes4
CoatingUncoated
SubstrateCobalt
Product TypeSquare End Mill
