Titan USA TE82303 | 0.1563" (5/32) Diameter x 0.3750" (3/8) Shank x 3.1250" (3-1/8) OAL x 0.4375" (7/16) LOC 4 Flute Uncoated Cobalt Square End Mill

$34.56
Brand:
Titan USA
Mill Diameter (Inch):
5/32"
Mill Diameter (Decimal Inch):
0.1563"
Mill Diameter (mm):
3.97mm
Number of Flutes:
4
Length of Cut (Inch):
7/16"
Length of Cut (Decimal Inch):
0.4375"
Length of Cut (mm):
11.11mm
Material:
Cobalt
Finish/Coating:
Uncoated
Shank Diameter (Inch):
3/8"
Shank Diameter (Decimal Inch):
0.3750"
Shank Diameter (mm):
9.53mm
Overall Length (Inch):
3-1/8"
interval quantity:
1
SKU:
25231683
Weight:
0.07 LBS
Shipping:
Calculated at Checkout

CNC ground in the USA from M42 cobalt, this Titan USA fully stocked offering of Double-Ended General Purpose End Mills features CNC cutting tools with 4 flutes, a square profile, and a 30 Degree helix angle.

Features:

  • Double-ended
  • 4 flutes
  • Center cutting
  • Weldon flat
  • AlTiN coating offers increased wear and heat resistance
  • M42 cobalt
  • CNC ground in the USA

Product Specifications
Manufacturer Part NumberTE82303
Cutting Diameter (Inch)0.1563" (5/32)
Shank Diameter 0.3750" (3/8)
Overall Length (Inch)3.1250" (3-1/8)
Length of Cut (Inch)0.4375" (7/16)
Number of Flutes4
CoatingUncoated
SubstrateCobalt
Product TypeSquare End Mill
