With spiral flutes for through and blind hole applications, these Titan USA high speed steel reamers are precision manufactured in the USA and are fully stocked in 6 to 12 flute options.
Features:
- General purpose reamers featuring a 45 Degree chamfer angle
- Spiral flutes for increased chip evacuation in blind hole applications
- High speed steel
- Precision manufactured in the USA
Product Specifications
| Manufacturer Part Number | TR97655 |
| Reamer Diameter (Inch) | 1.2120" |
| Minor Diameter (Inch) | 1.1030" |
| Across Flat (Inch) | 0.8430" (27/32) |
| Margin Length (Inch) | 1.7500" (1-3/4) |
| Shank Diameter (Inch) | 1.1250" (1-1/8) |
| Overall Length (Inch) | 3.7500" (3-3/4) |
| Number of Flutes | 8 |
| Size | 1 |
| Substrate | High Speed Steel |
| Coating | Uncoated |
| Product Type | Taper Pipe Reamer |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Titan USA
Pipe Size (Inch):
1"
Pipe Size (Decimal Inch):
1.0000"
Pipe Size (mm):
25.40mm
Small End Diameter (Inch):
1-7/68"
Small End Diameter (Decimal Inch):
1.1030"
Small End Diameter (mm):
28.02mm
Large End Diameter (Inch):
1-7/33"
Large End Diameter (Decimal Inch):
1.2120"
Large End Diameter (mm):
30.78mm
Flute Length (Inch):
1-3/4"
Flute Length (Decimal Inch):
1.7500"
Flute Length (mm):
44.45mm
Overall Length (Inch):
3-3/4"
Overall Length (Decimal Inch):
3.7500"
Overall Length (mm):
95.25mm
Material:
High Speed Steel
Finish/Coating:
Uncoated
