Features:
- Taps are on blanks that meet ANSI specifications
- High speed steel
- CNC ground in the USA
Product Specifications
| Manufacturer Part Number | TT75203 |
| Shank Diameter (Inch) | 0.1410" |
| Length of Cut (Inch) | 0.3125" (5/16) |
| Across Flat (Inch) | 0.1100" |
| End Length (Inch) | 0.1875" (3/16) |
| Overall Length (Inch) | 1.6250" (1-5/8) |
| Thread Size (Inch) | 0-80 |
| Number of Flutes | 2 |
| Limit | H1 |
| Coating | TiN |
| Substrate | High Speed Steel |
| Product Type | Tap Set |
