Features:
- For optimal results, use a taper tap for an initial pass, prior to using a Plug or Bottom Tap to finish the thread
- Taps are on blanks that meet ANSI specifications
- TiN coating provides improved performance in a wide variety of materials, and generally used in applications with lower cutting speeds
- High speed steel
- CNC ground in the USA
Product Specifications
| Manufacturer Part Number | TT75708 |
| Shank Diameter (Inch) | 0.1410" |
| Length of Cut (Inch) | 0.5000" (1/2) |
| Across Flat (Inch) | 0.1100" |
| End Length (Inch) | 0.1875" (3/16) |
| Overall Length (Inch) | 1.8125" (1-13/16) |
| Thread Size (mm) | M2.5 X 0.45 |
| Number of Flutes | 3 |
| Limit | D3 |
| Type | Plug |
| Coating | TIN |
| Substrate | High Speed Steel |
| Product Type | Straight Flute Tap |
