Features:
- For optimal results, use a taper tap for an initial pass, prior to using a Plug or Bottom Tap to finish the thread
- Taps are on blanks that meet ANSI specifications
- TiN coating provides improved performance in a wide variety of materials, and generally used in applications with lower cutting speeds
- High speed steel
- CNC ground in the USA
Product Specifications
| Manufacturer Part Number | TT75796 |
| Shank Diameter (Inch) | 0.4800" |
| Length of Cut (Inch) | 1.8125" (1-13/16) |
| Across Flat (Inch) | 0.3600" |
| End Length (Inch) | 0.5625" (9/16) |
| Overall Length (Inch) | 3.8125" (3-13/16) |
| Thread Size (mm) | M16 X 2.0 |
| Number of Flutes | 4 |
| Limit | D7 |
| Type | Bottom |
| Coating | TIN |
| Substrate | High Speed Steel |
| Product Type | Straight Flute Tap |
