Features:
- For optimal results, use a Taper Tap for an initial pass, prior to using a Plug or Bottom Tap to finish the thread
- Taps are on blanks that meet ANSI specifications
- High speed steel
- CNC ground in the USA
Product Specifications
| Manufacturer Part Number | TT9042 |
| Shank Diameter | 0.3810" |
| Overall Length (Inch) | 2.9375" (2-15/16) |
| Length of Cut (Inch) | 1.2500" (1-1/4) |
| Thread Size | 3/8"-16 |
| End Length (Inch) | 0.4375" (7/16) |
| Type | Bottom |
| Thread Limit | H3 |
| Number of Flutes | 3 |
| Coating | Uncoated |
| Substrate | high speed steel |
| Product Type | Straight Flute Tap |
