Features:
- For optimal results, use a Taper Tap for an initial pass, prior to using a Plug or Bottom Tap to finish the thread
- Taps are on blanks that meet ANSI specifications
- High speed steel
- CNC ground in the USA
Product Specifications
| Manufacturer Part Number | TT90563 |
| Shank Diameter | 0.4800" |
| Overall Length (Inch) | 3.8125" (3-13/16) |
| Length of Cut (Inch) | 1.8125" (1-13/16) |
| Thread Size | 5/8"-11 |
| End Length (Inch) | 0.5625" (9/16) |
| Type | Bottom |
| Thread Limit | H3 |
| Number of Flutes | 4 |
| Coating | Uncoated |
| Substrate | high speed steel |
| Product Type | Straight Flute Tap |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
