CNC ground in the USA from high speed steel onto blanks that meet ANSI specifications.
Features:
- General purpose spiral point plug taps
- Taps are on blanks that meet ANSI specifications
- AlTiN coating offers increased wear and heat resistance
- Steam Oxide finish provides decreased galling and increased lubricity in low carbon steels and gummy materials
- Nitride & Steam Oxide finish provides increased surface hardness and acts as a lubricant and also retains liquid lubricant at cutting edge. Prevents chip welding and reduces friction
- High speed steel
- CNC ground in the USA
Product Specifications
| Manufacturer Part Number | TT91085NS |
| Across Flat (Inch) | 0.2750" |
| Length of Cut (Inch) | 1.6563" |
| End Length (Inch) | 0.4375" (7/16) |
| Shank Diameter (Inch) | 0.3670" |
| Overall Length (Inch) | 3.3750" (3-3/8) |
| Thread Size (Inch) | 1/2"-13 |
| Number of Flutes | 3 |
| Limit | H3 |
| Type | SP/PT Plug |
| Substrate | High Speed Steel |
| Coating | Nitride & Steam Oxide |
| Product Type | Spiral Point Tap |
