This Titan USA offering of general purpose, High Speed Steel Plug Taps feature TiN coating, which provides improved performance in a wide variety of materials, and is generally used in applications with lower cutting speeds.
Features:
- General purpose spiral point plug taps
- Spiral point for through-hole applications
- Taps are on blanks that meet ANSI specifications
- TiN coating provides improved performance in a wide variety of materials, and generally used in applications with lower cutting speeds
- High speed steel
- CNC ground in the USA
Product Specifications
| Manufacturer Part Number | TT92267 |
| Across Flat (Inch) | 0.2380" |
| Length of Cut (Inch) | 1.1250" (1-1/8) |
| End Length (Inch) | 0.3750" (3/8) |
| Shank Diameter (Inch) | 0.3180" |
| Overall Length (Inch) | 2.7188" |
| Thread Size (Inch) | 5/16-24 |
| Limit | H3 |
| Type | SP/PT Bottom |
| Coating | TIN |
| Substrate | High Speed Steel |
| Number of Flutes | 2 |
| Product Type | Spiral Point Tap |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Titan USA
Shank Diameter (Decimal Inch):
0.3180"
Shank Diameter (mm):
8.08mm
Length of Cut (Inch):
1-1/8"
Length of Cut (Decimal Inch):
1.1250"
Length of Cut (mm):
28.58mm
Overall Length (Decimal Inch):
2.7188"
Overall Length (mm):
69.06mm
Number of Flutes:
2
Finish/Coating:
TiN
Material:
High Speed Steel
