Features:
- High speed steel
- Spiral point for through-hole applications
- Taps are on blanks that meet ANSI specifications
- Oversized to produce threads that accept coil wire screw thread inserts of the same size and pitch
- CNC ground in the USA
Product Specifications
| Manufacturer Part Number | TT92343 |
| Across Flat (Inch) | 0.1650" |
| Thread Length (Inch) | 0.9375" (15/16) |
| End Length (Inch) | 0.2813" |
| Shank Diameter (Inch) | 0.3180" |
| Overall Length (Inch) | 2.3750" (2-3/8) |
| Thread Size (Inch) | #12-24 |
| Number of Flutes | 2 |
| Limit | H2 |
| Coating | Uncoated |
| Substrate | High Speed Steel |
| Type | Plug |
| Product Type | Spiral Point STI Tap |
