This metric Titan USA offering features uncoated high speed steel hand taps that are CNC ground in the USA on blanks that meet ANSI specifications.
Features:
- For optimal results, use a Taper Tap for an initial pass, prior to using a Plug or Bottom Tap to finish the thread
- High speed steel
- CNC ground in the USA
Product Specifications
| Manufacturer Part Number | TT93076 |
| Across Flat (Inch) | 0.4890" |
| Length of Cut (Inch) | 2.0000" (2) |
| End Length (Inch) | 0.6875" (11/16) |
| Shank Diameter (Inch) | 0.6520" |
| Overall Length (Inch) | 4.4688" |
| Thread Size (Inch) | M20 X 2.5 |
| Number of Flutes | 4 |
| Limit | D7 |
| Type | Taper |
| Substrate | High Speed Steel |
| Coating | Uncoated |
| Product Type | Straight Flute Tap |
