This metric Titan USA offering features uncoated high speed steel hand taps that are CNC ground in the USA on blanks that meet ANSI specifications.
Features:
- For optimal results, use a Taper Tap for an initial pass, prior to using a Plug or Bottom Tap to finish the thread
- High speed steel
- CNC ground in the USA
Product Specifications
| Manufacturer Part Number | TT93096 |
| Across Flat (Inch) | 0.9250" |
| Length of Cut (Inch) | 3.0000" (3) |
| End Length (Inch) | 1.1250" (1-1/8) |
| Shank Diameter (Inch) | 1.2330" |
| Overall Length (Inch) | 6.0625" |
| Thread Size (Inch) | M36 X 4.0 |
| Number of Flutes | 4 |
| Limit | D9 |
| Type | Bottom |
| Substrate | High Speed Steel |
| Coating | Uncoated |
| Product Type | Straight Flute Tap |
