Tungaloy 6751939 | TID080F12-1.5 8.90mm Diameter x 72.25mm OAL Steel Replaceable-Tip Drills

$243.50
Brand:
Tungaloy
Maximum Cutting Diameter (Decimal Inch):
0.3504"
Minimum Cutting Diameter (Decimal Inch):
0.3149"
Flange Diameter (Decimal Inch):
0.6300"
Body Material:
Steel
Overall Length (Decimal Inch):
2.8440"
Point Length (Decimal Inch):
0.0470"
Shank Length (Decimal Inch):
1.7720"
Usable Length (Decimal Inch):
0.5510"
interval quantity:
1
SKU:
23128781
UPC:
Weight:
1.23 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout

Outer tubes, 4 start thread connection for double tube system. please indicate the length (OAL) when ordering.


Product Specifications
Cutting Diameter Maximum (mm)8.9 mm
Cutting Diameter Minimum (mm.)8 mm
Flange Diameter (mm)16 mm
Overall Length (mm)72.25mm
ApplicationBTA system

Warning:

This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.

For more information, visit www.P65Warnings.ca.gov

Brand:
Tungaloy
Maximum Cutting Diameter (Decimal Inch):
0.3504"
Minimum Cutting Diameter (Decimal Inch):
0.3149"
Flange Diameter (Decimal Inch):
0.6300"
Body Material:
Steel
Overall Length (Decimal Inch):
2.8440"
Point Length (Decimal Inch):
0.0470"
Shank Length (Decimal Inch):
1.7720"
Usable Length (Decimal Inch):
0.5510"
interval quantity:
1
