"DrillMeister" indexable head drill with flanged shank.
Product Specifications
| Cutting Diameter Maximum (mm) | 7.9 mm |
| Cutting Diameter Minimum (mm.) | 7.5 mm |
| Flange Diameter (mm) | 16 mm |
| Connection Diameter Machine Side (Inch) | 1-1/4" |
| Overall Length (mm) | 81.95mm |
| Point Length (Inch) | 0.143" |
| Shank Length (Inch)) | 2.362" |
| Shank Length (mm) | 1.589" |
| Insert Seat Size Code (SSC) | 24 |
| Coolant Supply Property (CSP) | Through Hole |
| Application | General Drilling |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Tungaloy
Maximum Cutting Diameter (Decimal Inch):
0.3110"
Minimum Cutting Diameter (Decimal Inch):
0.2952"
Flange Diameter (Decimal Inch):
0.6300"
Body Material:
Steel
Overall Length (Decimal Inch):
3.2260"
Point Length (Decimal Inch):
0.0440"
Shank Length (Decimal Inch):
1.7720"
Usable Length (Decimal Inch):
0.9450"
