"DrillMeister" indexable head drill with flanged shank.
Product Specifications
| Cutting Diameter Maximum (mm) | 8.9 mm |
| Cutting Diameter Minimum (mm.) | 8.5 mm |
| Flange Diameter (mm) | 16 mm |
| Connection Diameter Machine Side (Inch) | 1" |
| Overall Length (mm) | 85.75mm |
| Point Length (Inch) | 1/8" |
| Shank Length (Inch)) | 2.205" |
| Shank Length (mm) | 2.631" |
| Insert Seat Size Code (SSC) | 21 |
| Coolant Supply Property (CSP) | Through Hole |
| Application | General Drilling |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Tungaloy
Maximum Cutting Diameter (Decimal Inch):
0.3504"
Minimum Cutting Diameter (Decimal Inch):
0.3346"
Flange Diameter (Decimal Inch):
0.6300"
Body Material:
Steel
Overall Length (Decimal Inch):
3.3760"
Point Length (Decimal Inch):
0.0510"
Shank Length (Decimal Inch):
1.7720"
Usable Length (Decimal Inch):
1.1020"
interval quantity:
1
