Tungaloy 6791059 | 3QP-TNGA 330.5-LC BXA20 3/8" Circle Diameter x 0.187" Thickness x 0.008" Radius Polycrystalline Cubic Boron Nitride Indexable Turning Insert

$109.90 $101.11
(You save $8.79)
Brand:
Tungaloy
Material:
PCBN
Inscribed Circle (Inch):
3/8"
Corner Radius (Decimal Inch):
0.0079"
Manufacturer's Grade:
BXA20
Thickness (Decimal Inch):
0.1870"
interval quantity:
1
SKU:
23132345
UPC:
Weight:
1.23 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout

Negative relief angle, G class, triangular CBN insert.


Product Specifications
# MFG6791059
Corner Radius (Inch)0.008"
Cutting Edge Length (Inch)0.65"
Cutting Edge Effective Length (Inch)0.091"
Maximum Depth of Cut (Inch)0.0197"
Fixing Hole Diameter (Inch)0.15"
Inscribed Circle Diameter (Inch)3/8"
Insert Thickness (Inch)0.187"
Maximum Turning Feed (Inch)0.0098"/rev
Minimum Depth of Cut (Inch)0.002"
Minimum Turning Feed (Inch)0.0012"/rev
Cutting Edge MaterialPCBN
GradeBXA20
Tool TypeTurn Negative Inserts
Applicable MaterialHard Materials
Chip Breaker TypeLC-CBN
Body MaterialCarbide
