Tungaloy 6792034 | 2QP-DNGA 431 BXA10 1/2" Circle Diameter x 0.187" Thickness x 0.016" Radius Carbide Indexable Turning Insert

$71.50
Brand:
Tungaloy
Material:
Carbide
Inscribed Circle (Inch):
1/2"
Inscribed Circle (Decimal Inch):
0.5000"
Inscribed Circle (mm):
12.70mm
Thickness (Inch):
3/16"
Thickness (Decimal Inch):
0.1870"
Thickness (mm):
4.75mm
Corner Radius (Inch):
1/64"
Corner Radius (Decimal Inch):
0.0160"
Corner Radius (mm):
0.41mm
interval quantity:
1
SKU:
23132414
UPC:
Weight:
1.23 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout

Negative relief angle, G class, 55 degree rhombic CBN insert.


Product Specifications
# MFG6792034
Corner Radius (Inch)0.016"
Cutting Edge Length (Inch)0.61"
Cutting Edge Effective Length (Inch)0.098"
Maximum Depth of Cut (Inch)0.0197"
Fixing Hole Diameter (Inch)0.203"
Inscribed Circle Diameter (Inch)1/2"
Insert Thickness (Inch)0.187"
Maximum Turning Feed (Inch)0.0098"/rev
Minimum Depth of Cut (Inch)0.002"
Minimum Turning Feed (Inch)0.0012"/rev
GradeBXA10
Tool TypeTurn Negative Inserts
Applicable MaterialHard Materials
Chip Breaker TypeFT-CBN
Body MaterialCarbide
