Tungaloy 6795197 | 6QS-WNGA 431 BXA10 1/2" Circle Diameter x 0.187" Thickness x 0.016" Radius Carbide Indexable Turning Insert

$185.43
Brand:
Tungaloy
Material:
PCBN
Inscribed Circle (Inch):
1/2"
Corner Radius (Decimal Inch):
0.0157"
Manufacturer's Grade:
BXA10
Thickness (Decimal Inch):
0.1870"
interval quantity:
1
SKU:
23155988
UPC:
Weight:
1.23 LBS
Minimum Purchase:
2 units
Shipping:
Free Shipping

Negative relief angle, G class, trigon CBN insert, applied "WavyJoint" brazing technology.


Product Specifications
# MFG6795197
Corner Radius (Inch)0.0157"
Cutting Edge Length (Inch)0.343"
Cutting Edge Effective Length (Inch)0.063"
Maximum Depth of Cut (Inch)0.0315"
Fixing Hole Diameter (Inch)0.203"
Inscribed Circle Diameter (Inch)1/2"
Insert Thickness (Inch)0.187"
Maximum Turning Feed (Inch)0.0118"/rev
Minimum Depth of Cut (Inch)0.002"
Minimum Turning Feed (Inch)0.0012"/rev
GradeBXA10
Tool TypeTurn Negative Inserts
Applicable MaterialHard Materials
Chip Breaker TypeFT-Wavy
Body MaterialCarbide
